PNF350-2S
Le PNF350-2S est une scie à froid semi-automatique de bras de pivot qui est employée pour couper les métaux non ferreux.
Les acariens PNF350-2S de 45 à gauche à 45 degrés à droite. Il dispose également d'une tête de sciage robuste qui peut incliner 45 degrés pour la coupe de mitre composé. Ce modèle est équipé d'un coup de tête programmable.
Doté d'une capacité creuse ronde de 4 3/4 po à 90 degrés, d'un moteur de 2,5 po et d'une lame de 14 po, le PNF350-2S est le choix idéal pour une coupe rapide, propre et précise de métaux non ferreux.
- Semi-automatic operation
- Pneumatic operating saw head and vises, activated by push button control panel
- Robust sawing head can tilt 45° left for compound miter cutting
- Two blade speeds achieve speeds of 1700 or 3400 rpm
- Rotating table mounted on large roller bearings. Features stops at 90° and 45°.
- Two pneumatic operating vises, capable of sliding in or away from the blade to adjust saw head
- in mitered position
- Vises are equipped with moveable aluminum jaws which can be adjusted vertically
- 3.5/5 Hp blade drive coupled directly to saw head guarantees high rigidity and precision to
- obtain high chip removal rates.
- Cutting area enclosed behind protective cover which swings up for loading material
- Automatic coolant lubrication activates during the cut
- One carbide tipped blade included
- Material stop with ruler
- Foot pedal with e- stop
- T2500 chip collector
- Pneumatic vertical vise
- Roller table & accessories
